The Cat 906M (2015–2022) is a compact wheel loader for landscaping, municipal work, agriculture, and small-scale material handling. With an operating weight of about 5.6 t, bucket capacities from 0.8–1.0 m³, and net power around 55.5 kW (74 hp) from a Cat C3.3B diesel, it offers good lift for its size while staying maneuverable in tight sites. Hydrostatic drive, parallel-lift loader arms, and comfortable cab design make it versatile for year-round use.
Engine: Cat C3.3B, ~55.5 kW (74 hp)
Operating Weight: ~5,600 kg
Bucket Capacity: ~0.8–1.0 m³
Breakout Force: ~42–45 kN
Tipping Load (Straight): ~3,450 kg
Travel Speed: ~20–35 km/h (2-speed hydrostatic)
Hydraulics: Load-sensing, 100 L/min pump flow
Fuel Tank: ~80 L
Cat 906 Technical specifications
General
Engine model
Cat C3.3B
Operating weight
5,600 kg
Bucket width
1,800 mm
Bucket capacity
1 cu m
Lifting capacity
1800 kg
Max speed forward
32 kph
Max dump height
2300 mm
Tipping load
3,600 kg
Engine
Gross power
55.18 kw
Displacement
3300 cu cm
Max torque
360 Nm
Service refill capacities
Fuel cap
110 liter
Hydraulic fluid cap
40 liter
Hydraulic system
Pump type
Gear pump
Pump flow cap
75 lpm
Relief valve pressure
199.94 bar
Dimensions
Height - top of cab
2.55 m
Wheelbase
1.9 m
Loader
Breakout force
38 kN
Operating specifications
Max dump reach
760 mm
Rack back angle
40 º
Cat 906 expert review
Overview
Compact loader for landscaping, municipal, and farm work. Tight turning, parallel-lift arms, and good visibility make it versatile year-round.
Parallel lift improves load stability.
Hydrostatic drive not ideal for long travel.
Performance & Efficiency
Hydrostatic transmission makes it nimble. Parallel-lift arms keep loads level. Load-sensing hydraulics improve control and fuel efficiency.
In Comparison
Volvo L25F matches size with more bucket capacity; JCB 406 offers more clearance but less refined cab.
Verdict
Best suited for operators needing agility over volume in compact loader work.
Cat 906 owner rating
2015-2022
Overall rating
Based on 0 ratings
0 %
100 %
0 %
0 %
0 %
